| Resolution |
640×480 |
| Interface |
USB-HID; Bluetooth: HID, BLE, SPP |
| Dimensions (WHD) |
46mm × 38.5mm × 128mm |
| Lithium Battery |
1000mAh |
| Cable Length |
1M |
| Materials |
ABS+PC |
| Light Sources |
617nm LED Aimer, White LED |
| Scan Type |
Image scan |
| Precision |
≥5mil |
| Scan Angle |
Yaw ±45°, Rotation 360°, Pitch ±45° |
| Depth of Scan Field |
EAN-13 (13mil): 4-25cm; Code39 (4mil): 4-10cm; QR code (15mil): 2-170cm |
| Error Rate |
1/5 million |
| Relative Humidity |
5% ~ 95% RH (Non-condensing) |
| Shock Resistance |
Withstands multiple 1.5-meter drops to concrete |
| Field of View |
48°(H) × 36°(V) |
| Ambient Lighting |
0 ~ 100000LUX |
| Standby Current |
0mA (Standby cuts off battery power) |
| Scan Mode |
Manual/Continuous/Automatic Induction Scanning |
| Wireless Transmission Distance |
50-100 meters (open distance) |
| Storage Mode |
Offline Storage Mode: Stores data when scanner exits connection range (512,000 characters); Inventory Storage Mode: Scanner can enter inventory mode (512,000 characters) |
| Pairing Mode |
One-to-one: One scanner paired with one receiver or a scanner paired with a Bluetooth mobile device |
| Operating Temperature |
-20°C to 50°C |
| Storage Temperature |
-40°C to 70°C |
| Working Voltage |
DC 5V ±5% |
| Charging Time |
3-3.5h |
| Wireless Communication |
Pairing dedicated receiver: 2.4G communication; Pairing Mobile Bluetooth Devices: Dual Mode Bluetooth |
| Supported Codes (1D) |
Code 128, EAN-13, EAN-8, UPC-E, UPC-A, ISBN, ISSN, Code11, ITF-25 (Interleaved 2 of 5), Code39, Code93, Code32, Codaba, Matrix 2 of 5, Industrial 25, IATA 25, MSI Plessey |
| Supported Codes (2D) |
QR Code, Micro QR, Data Matrix, PDF417, Micro PDF417, Aztec |
| Pairing Method |
Pair by barcode; Set up pairing via screen |
| Contrast |
≥20% |
| Screen Function |
View barcode data in real-time; View stored data in real-time; Check power in real-time; Real-time display; Scanner can be set through the screen |
| Continuous Working Hours |
4 hours continuous, more than 8 hours intermittent |
| Working Current |
>26mA (without scanning), ≥250mA (when scanning) |
| Charging Method |
TYPE-C charging cable, plug-in direct charging |
| Receiving End |
Dedicated Bluetooth U disk receiver, Android/iOS mobile device |
