| Resolution |
640*480 |
| Interface |
USB-HID |
| Light Sources |
617nm LED Aimer, White LED |
| Supported Symbologies |
1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleave 2 of 5, ITF-6, ITF-4, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5. 2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Micro QR, Micro PDF417, Hanxin Code. |
| Precision |
≥5mil |
| Scan Angle |
Yaw ±55°, Rotation 360°, Pitch ±55° |
| Depth of Scan Field |
EAN13 50-200mm (13mil); QR 25-240mm (20mil); PDF417 30-130mm (6.67mil) |
| Error Rate |
1/5 million |
| Print Contrast |
≥20% |
| Scan Mode |
Manual/Continuous/Automatic Induction Scanning |
| Wireless Transmission Distance |
30-50 meters (open distance) |
| Storage Mode |
Offline Storage Mode: When the scanner exits the connection range, the data is automatically stored. Storage capacity is 512000 characters. Inventory storage mode: Scanner can enter inventory mode, storage capacity is 512000 characters. |
| Pairing Mode |
One to One: One Scanning Gun Pairs One Receiver; One scanner paired with a Bluetooth mobile device |
| Operating Temperature |
-20°C ~ 50°C |
| Storage Temperature |
-40°C ~ 70°C |
| Working Voltage |
DC5V ± 5% |
| Charging Time |
5h |
| Battery Working Time |
7h |
| Operating Current |
When not scanning code ≥26mA; when scanning code ≥280mA |
| Charging Model |
Square USB charging cable, plug straight charge |
